SKU:MKB-CRG-000001

Rippa

Mini track loader RIPPA RS04-T

Mini track loader RIPPA RS04-T

Regular price €5.700,00 EUR + IVA
Regular price Sale price €5.700,00 EUR
Sale Sold out
Shipping calculated at checkout.

The RIPPA RS04-T is the rubber track version designed to deliver maximum stability, superior traction, and lower ground pressure. Powered by a Kubota Z482 diesel engine, it is the ideal tool for demanding jobs on soft terrain, mud, sand, uneven surfaces, or landscaped areas where minimizing ground impact is critical.

Its compact chassis and powerful hydraulic system allow it to maneuver smoothly through narrow passages without compromising lifting capacity.

Key Advantages of the Tracked Version

  • Superior Traction: Excellent grip and pushing force in mud, sand, snow, and on slopes up to 25%.
  • Low Ground Pressure: Weight distribution over the tracks' footprint prevents sinking into soft ground and preserves lawns or landscaped areas.
  • Enhanced Stability: Greater platform firmness when operating on uneven ground or lifting heavy loads to maximum height.
  • Technical Specifications (RIPPA RS04-T)
Parameter Specification
Model RIPPA RS04-T
Drive system Rubber Tracks
Operating weight 890 kg
Rated working load 175 kg
Max lifting capacity 400 kg
Bucket capacity 0.15 m³
Bucket / Machine width 1,150 mm
Max lifting height 2,080 mm
Max dumping height 1,553 mm
Travel speed 0 – 4.5 km/h
Gradeability 25%

Engine & Performance

Feature Value
Make / Model Kubota Z482 (Japan)
Fuel type Diesel
Cylinders 2 cylinders (Water-cooled)
Rated power 8.3 kW / 11.1 HP
Displacement 0.479 L
Estimated fuel consumption 0.8 – 1.2 L/h

Transport Dimensions

Dimension Measurement
Overall length (with bucket) 1,970 mm
Overall length (without bucket) 1,520 mm
Overall width 1,150 mm
Overall height 1,300 mm
Ground clearance 108 mm

Contact us for more information: 📧 info@makiboom.com 📱 🇮🇹 +39 334 8688611 -🇪🇸 +34 695 082847

View full details

Request information about Mini track loader RIPPA RS04-TWould you like more technical details, delivery times, or to try the machine? Write to us and we’ll get back to you with no obligation.
